Yaman Steel has built a solid reputation as a reliable manufacturer and supplier of Incoloy 825 pipe fittings right in Mumbai, India. They provide top-notch alloy solutions that cater to industries around the globe. Incoloy 825 is a unique nickel-iron-chromium alloy, enhanced with molybdenum, copper, and titanium, which gives it remarkable resistance to sulfuric and phosphoric acids, as well as to chloride stress corrosion cracking and pitting. Typically, this alloy contains between 38–46% nickel, 19.5–23.5% chromium, and a balanced amount of iron. These pipe fittings are known for their impressive tensile strength, toughness, and ductility across a wide range of temperatures, making them perfect for challenging environments in the chemical, marine, and industrial sectors.
Yaman Steel’s Incoloy 825 pipe fittings are crafted from a stabilized nickel-iron-chromium alloy, with precise additions of molybdenum, copper, and titanium. This specific chemical makeup guarantees exceptional resistance in both oxidizing and reducing conditions. Generally, these fittings boast a tensile strength of about 550 MPa, a yield strength of roughly 240 MPa, and an elongation rate nearing 30%. These mechanical characteristics ensure they are easy to weld and form, while also providing long-lasting structural stability, which is crucial for reliable performance under high pressure and elevated temperatures.
| Spec Chart Of: | Incoloy 825 Pipe Fittings |
| Dimension Table Of: | ANSI B16.9, JIS B2312, MSS-SP-43 Type B, ASME B16.28, JIS B2313, MSS-SP-43 Type A |
| Fittings Materials Directory: | Iron (Ductile/Cast), Carbon Steel, Titanium, Nickel Alloys, Nickel, Cupro-Nickel 90/10 & 70/30, Brass, Bronze, Copper, Chrome-molybdenum, Inconel, Monel, Tantalum, Stainless Steel, Hastalloy, Alloy Steel |
| Size Calculation: | Normal Pipe Size (1⁄₂”) to Normal Pipe Size (48”) |
| Standard Fittings Chart | JIS, NPT, ISO, DIN, EN |
| Manimum Pressure | Class 150# To Class 2500#. |
| Schedule Chart: | Schedule 5s/ Schedule 10s/ Schedule 40/ Schedule 80/ Schedule 120/ Schedule 160. |
| Most Demanded Fittings Types | Adapter, 4 Wye, End Cap, Stub End, Reducer, Cross, Bend, Elbow, Tee |
| Buttweld Fittings Connection Type | Threaded/ Weld/ Flange/ Clamp End / End Bell |
| The Chemical Composition of Incoloy 825 Pipe Fittings, % | |
|---|---|
| Nickel | 38.0-46.0 |
| Iron | ≥22.0 |
| Chromium | 19.5-23.5 |
| Molybdenum | 2.5-3.5 |
| Copper | 1.5-3.0 |
| Titanium | 0.6-1.2 |
| Carbon | ≤0.05 |
| Manganese | ≤1.00 |
| Sulfur | ≤0.030 |
| Silicon | ≤0.50 |
| Aluminum | ≤0.20 |
| Tensile Strength, min. | Yield Strength, min. | Elongation, min. | Elastic Modulus | |||
|---|---|---|---|---|---|---|
| Mpa | % | Gpa | 106psi | ksi | Mpa | ksi |
| 690 | 45 | 206 | 29.8 | 100 | 310 | 45 |
Yaman Steel is the largest manufacturer and exporter of Pipe, Fittings, Flanges in Mumbai, India, known for delivering high-quality products to clients across the globe. With state-of-the-art manufacturing facilities and a team of skilled professionals, the company ensures flanges with superior strength, durability, and reliability that meet international standards. Yaman Steel offers a wide range of sizes, grades, and specifications, catering to industries such as oil and gas, petrochemical, power, and water treatment. For inquiries and orders, contact us at sales@pipefittingsflanges.com.
You’ll find Yaman Steel’s Incoloy 825 pipe fittings widely used in industries where corrosion resistance and mechanical integrity are paramount. Common applications include chemical processing plants, offshore oil and gas systems, marine piping, nuclear fuel reprocessing units, and equipment for handling acids. They are particularly well-suited for heat exchangers, pickling plants, pollution control systems, and fertilizer manufacturing facilities. Thanks to their resistance to stress corrosion cracking, crevice corrosion, and harsh chemicals, these fittings are ideal for high-temperature and high-pressure operations in power generation and desalination industries.
