Yaman Steel stands out as a reliable manufacturer and supplier of Monel pipe fittings right in the heart of Mumbai, India. They specialize in high-performance nickel-copper alloy solutions that are perfect for corrosive and marine environments. Monel alloys are renowned for their remarkable resistance to seawater corrosion, hydrofluoric acid, and alkaline substances. These pipe fittings not only offer exceptional strength and precise dimensions but also boast a long service life, making them a top choice for piping systems that face tough chemical and saline conditions.
The Monel pipe fittings from Yaman Steel are crafted from nickel-copper alloys, with carefully controlled amounts of iron and manganese added to enhance their mechanical properties and corrosion resistance. This material showcases impressive tensile and yield strength, along with excellent ductility and dependable weldability. Thanks to these qualities, the fittings can maintain their structural integrity even under high pressure, temperature fluctuations, and challenging service conditions.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : Seamless Butt Weld Fittings : 1/2″ – 10″ | Welded Butt Weld Fittings : 1/2″ – 48″
Schedule : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / ERW / Welded / Fabricated
Thickness :20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc.
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Monel 400 | 63.0- 70.00 max | 2.50 max | 0.3 max | 2.00 max | 0.50 max | Remainder | – | – | 0.024 max |
| Monel K500 | 63.0 min | 05 – 2 | 0.25 max | 1.5 max | 0.5 max | 27.0 – 33.0 | 2.3 – 3.15 | 0.35 – 0.85 | 0.010 max |
| Grade | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
|---|---|---|---|---|
| 400 | 75 to 90 | 25 to 50 | 60 to 35 | 60 to 80 |
| K500 | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15,000 , MPa – 790 | 20 % | – |
Yaman Steel is the largest manufacturer and exporter of Pipe, Fittings, Flanges in Mumbai, India, known for delivering high-quality products to clients across the globe. With state-of-the-art manufacturing facilities and a team of skilled professionals, the company ensures flanges with superior strength, durability, and reliability that meet international standards. Yaman Steel offers a wide range of sizes, grades, and specifications, catering to industries such as oil and gas, petrochemical, power, and water treatment. For inquiries and orders, contact us at sales@pipefittingsflanges.com.
Yaman Steel’s Monel pipe fittings find their place in various industries, including marine engineering, offshore oil and gas, chemical processing, power generation, and heat exchangers. They are commonly used in seawater piping, brine systems, acid handling equipment, and refinery process lines. With their outstanding resistance to both corrosion and erosion, Monel pipe fittings are well-suited for long-term use in demanding industrial settings.
